Electrical BIM Modeler & CAD Draftsman - Water Treatment Plant Construction

Water Treatment Plant Construction project requiring skilled Electrical BIM Modeler & CAD Draftsman to prepare technical drawings, schematics, and BIM models for industrial and utility plant infrastructure.

Key Responsibilities:

• Preparation of SLDs, Schematics, Electrical Layouts & Control Wiring Drawings
• Create and manage Revit (MEP) and AutoCAD models
• Generate 2D Drawings, Isometrics & Sections from BIM models
• Preparation of Cable Routing, Cable Trench, Cable Tray & BOM/Cable Schedules
• Perform Clash Detection and multidisciplinary BIM coordination
• Substation, MCC, Transformer & Switchgear Layouts design
